Name Function
K
[ ][ ][ ][ ]
buttons
• Press to adjust focus, distortion, zoom, and lens shift.
s "Adjusting the Position of the Projected Image
(Lens Shift)" p.33
s "Adjusting the Image Size" p.36
s "Correcting the Focus" p.37
• When the Configuration menu or the Help screen is
displayed, pressing these buttons selects menu items
and setting values.
s "Using the Configuration Menu" p.134
• When using the optional wireless mouse receiver,
pressing these buttons moves the pointer.
s "Optional Accessories" p.217
L
[ ] button
• When the Configuration menu or the Help screen is
displayed, it accepts and enters the current selection and
moves to the next level.
s "Using the Configuration Menu" p.134
• Acts as a mouse's left button when using the optional
wireless mouse receiver.
s "Optional Accessories" p.217
M
[A/V Mute] button
Turns the video and audio on or off.
s "Hiding the Image and Sound Temporarily (A/V
Mute)" p.118
N
[Page] buttons
[[][]]
• Moves to the previous or next image file when
projecting images from a computer connected via a
network.
• When using the optional wireless mouse receiver, you
can change the PowerPoint file page during projection
by pressing the page up/page down buttons.
O
[Volume] buttons
[a][b]
[a] Decreases the volume.
[b] Increases the volume.
s "Adjusting the Volume" p.61
P
[ ] button
Displays the Info menu from the Configuration menu.
s "Info Menu (Display Only)" p.154
Name Function
Q
[User1] button
[User2] button
[User3] button
Select any frequently used item from the Configuration
menu items, and assign it to any of these buttons. By
pressing the button, the assigned menu item selection/
adjustment screen is displayed, allowing you to make one-
touch settings/adjustments.
s "Settings Menu" p.140
R
Numeric buttons
• Enter the Password.
s "Setting Password Protection" p.127
• Use this button to enter numbers in Network settings
from the Configuration menu.
S
[ID] button
Hold down this button and press the numeric buttons to
select the ID for the projector you want to operate using
the remote control.
s "ID Settings" p.41
T
[ID] switch
Use this switch to enable (On)/disable (Off) ID settings for
the remote control.
s "ID Settings" p.41
U
Remote port
Connects the optional remote control cable set and
outputs signals from the remote control.
s "Optional Accessories" p.217
When the remote control cable is plugged into this remote
port, the remote control light-emitting is disabled.
V
[ ] button
Displays and closes the Home screen.
s "Home screen" p.57
W
[Num] button
Hold down this button and press the numeric buttons to
enter passwords and numbers.
s
"Setting Password Protection" p.127
X
[Geometry] button
Corrects distortion in the projected image.
s "Correcting Distortion in the Projected Image"
p.62
Y
[Memory] button
Performs operations and makes settings for the memory
function.
s "Memory Function" p.122
Part Names and Functions
20
