When using the ELPLU02, a message prompting you to manually
adjust the distortion is displayed. Turn the distortion ring
counterclockwise, and then adjust the focus. After adjusting the focus,
manually turn the distortion ring to correct the image warping.
Registering and Loading Lens Adjustment Values
You can register a lens position whose lens shift, zoom, focus, and
distortion was adjusted in memory, and load it when necessary. You can
register up to 10 values.
a
• This feature cannot be used if the following lenses are attached.
ELPLS04, ELPLU02, ELPLR04, ELPLW04, ELPLM06, ELPLM07,
ELPLL07
• If you did not calibrate your lens, a message is displayed when you
save a memory. Select Yes to calibrate the lens.
• The lens position when a memory is loaded may not completely
match the lens position when the memory was saved.
• If there is a large discrepancy between the lens position when a
memory is loaded and the lens position when the memory was
saved, calibrate the lens.
s Extended - Operation - Lens Calibration p.142
a
Press the [Memory] button while projecting.
a
You can also operate from the Configuration menu.
s Settings - Memory p.140
b
Select Lens Position, and then press the [ ] button.
c
Select the function you want to perform, then press the [ ]
button.
Installing the Projector
39
