Epson EB-G7200W - Elplx01; Elplu03

Unit: cm
16:10 Screen Size
AB
Minimum (Wide) to
Maximum (Tele)
Vertical Lens Shift
Top to Bottom
48" 103x65 150 - 243 -77 - +12
50" 108x67 156 - 254 -80 - +13
60" 130x81 189 - 305 -96 - +15
80" 172x108 253 - 408 -128 - +21
100" 215x135 318 - 512 -160 - +26
120" 258x162 382 - 615 -192 - +31
150" 323x202 479 - 770 -241 - +39
200" 431x269 640 - 1028 -321 - +51
250" 538x337 802 - 1286 -401 - +64
280" 603x377 899 - 1441 -449 - +72
ELPLX01
See the user's guide supplied with the lens unit.
ELPLU03
Unit: cm
4:3 Screen Size
AB
Minimum (Wide) to
Maximum (Tele)
Vertical Lens Shift
Top to Bottom
80" 163x122 107 - 129 -131 - +9
100" 203x152 134 - 162 -164 - +12
120" 244x183 162 - 196 -197 - +14
150" 305x229 204 - 245 -246 - +17
4:3 Screen Size
AB
Minimum (Wide) to
Maximum (Tele)
Vertical Lens Shift
Top to Bottom
200" 406x305 273 - 328 -328 - +23
250" 508x381 342 - 411 -410 - +29
300" 610x457 411 - 494 -492 - +35
Unit: cm
16:9 Screen Size
AB
Minimum (Wide) to
Maximum (Tele)
Vertical Lens Shift
Top to Bottom
74" 164x92 108 - 130 -117 - +25
80" 177x100 117 - 141 -126 - +27
100" 221x125 147 - 177 -158 - +33
120" 266x149 177 - 213 -189 - +40
150" 332x187 222 - 268 -237 - +50
200" 443x249 297 - 358 -316 - +67
250" 553x311 373 - 448 -395 - +83
275" 609x342 410 - 493 -434 - +92
Unit: cm
16:10 Screen Size
AB
Minimum (Wide) to
Maximum (Tele)
Vertical Lens Shift
Top to Bottom
76" 164x102 108 - 130 -122 - +20
80" 172x108 113 - 137 -128 - +21
100" 215x135 143 - 172 -160 - +26
120" 258x162 172 - 208 -192 - +31
150" 323x202 216 - 260 -241 - +39
Screen Size and Projection Distance
229
