Unit: cm
16:9 Screen Size
AB
Minimum (Wide) to
Maximum (Tele)
Vertical Lens Shift
Top to Bottom
46" 102x57 165 - 228 -73 - +15
50" 111x62 180 - 248 -79 - +17
60" 133x75 218 - 299 -95 - +20
80" 177x100 293 - 401 -126 - +27
100" 221x125 368 - 503 -158 - +33
120" 266x149 443 - 605 -189 - +40
150" 332x187 556 - 759 -237 - +50
200" 443x249 743 - 1014 -316 - +67
250" 553x311 931 - 1269 -395 - +83
275" 609x342 1025 - 1397 -434 - +92
Unit: cm
16:10 Screen Size
AB
Minimum (Wide) to
Maximum (Tele)
Vertical Lens Shift
Top to Bottom
48" 98x73 168 - 231 -77 - +12
50" 108x67 175 - 241 -80 - +13
60" 130x81 212 - 291 -96 - +15
80" 172x108 285 - 390 -128 - +21
100" 215x135 358 - 489 -160 - +26
120" 258x162 431 - 589 -192 - +31
150" 323x202 540 - 738 -241 - +39
200" 431x269 723 - 986 -321 - +51
250" 538x337 906 - 1234 -401 - +64
16:10 Screen Size
AB
Minimum (Wide) to
Maximum (Tele)
Vertical Lens Shift
Top to Bottom
280" 603x377 1015 - 1383 -449 - +72
ELPLM09/ELPLS04
Unit: cm
4:3 Screen Size
AB
Minimum (Wide) to
Maximum (Tele)
Vertical Lens Shift
Top to Bottom
50" 102x76 219 - 358 -82 - +6
60" 122x91 265 - 431 -98 - +7
80" 163x122 356 - 578 -131 - +9
100" 203x152 447 - 724 -164 - +12
120" 244x183 538 - 870 -197 - +14
150" 305x229 674 - 1090 -246 - +17
200" 406x305 902 - 1456 -328 - +23
250" 508x381 1129 - 1822 -410 - +29
300" 610x457 1357 - 2188 -492 - +35
Unit: cm
16:9 Screen Size
AB
Minimum (Wide) to
Maximum (Tele)
Vertical Lens Shift
Top to Bottom
46" 102x57 220 - 359 -73 - +15
50" 111x62 240 - 391 -79 - +17
60" 133x75 289 - 471 -95 - +20
80" 177x100 389 - 630 -126 - +27
Screen Size and Projection Distance
