Point Correction
Divides the projected image by the grid and corrects the distortion by
moving the point of intersection from side to side and up and down.
a
• You can make corrections by 0.5 pixels in each direction in the
following ranges.
EB-G7905U/EB-G7900U/EB-G7500U/EB-G7400U: Maximum of 32
pixels in the vertical and horizontal directions
EB-G7200W/EB-G7000W/EB-G7805/EB-G7800/EB-G7100: Maximum
of 20 pixels in the vertical and horizontal directions
• If 4K Enhancement is enabled, a message is displayed. Select Yes to
disable 4K Enhancement. (EB-G7905U/EB-G7900U/EB-G7500U/EB-
G7400U only)
s Image - Image Enhancement - 4K Enhancement p.137
a
Press the [Menu] button while projecting.
b
Select Geometric Correction from Settings.
c
Select Point Correction, and then press the [ ] button.
If the message "If this setting is changed, the image may be
distorted." is displayed, press the [
] button.
d
Select Point Correction, and then press the [ ] button.
e
Select Point Correction, and then press the [ ] button.
Point Correction
Select the point number (3x3, 5x5, 9x9, 17x17),
and then make the Point Correction setting.
Pattern Color
Select the color of the grid when performing
corrections.
Reset
Resets all corrections for Point Correction to their
default values.
f
Select the point number (3x3, 5x5, 9x9, or 17x17), and then press
the [
] button.
Adjusting Projected Images
86
To Next Page
