Setting the Projector
135
d
Make necessary settings on the Multi-Projection menu
For details on making settings, see the projector's User's Guide.
Edge Blending
Black Level
Adjust the image overlapping section to create a seam‐
less image.
(
s"Figures of Installation Dimensions" p.13)
Scale
Set the magnification and splicing position for the im‐
age.
Light Source Mode Adjust the brightness of the entire image. Select Cus‐
tom, and then adjust the Brightness Level based on the
darkest projector.
Color Uniformity
Color Matching
RGBCMY
Adjust the color of the image for each projector so that
the entire image looks uniform.
Projector Sync. Settings (only when using interactive functions)
Connect the projectors in advance by using the remote control cable set (ELPKC28). For details,
see "Connecting Multiple Projectors" p.16.
a
Press the [Menu] button
Using the Remote Control Using the Control Panel
b
Select Installation of Projectors from the Pen/Touch menu
To Next Page
