Installing the Touch Unit
93
Notes on the Touch Unit Bracket
Caution
If there is a frame around the screen, make sure that the thickness of the top of the frame
is less than 3 mm.
If the thickness of the top of the screen exceeds 3 mm, the Touch Unit will not operate correctly.
0-3mm
Make sure that the distance from the wall to the surface of the screen is less than 50 mm.
You cannot install the Touch Unit Bracket if the distance is more than 50 mm.
15-50mm
To Next Page
