Epson ELPFT01 - Installation Procedure for the Wall Mount

Installing the Wall mount
29
Mini PC installation plate
8xΦ5
4xΦ3.8
102
116
100
75
14.7
22.7
35.2
130
145.5
21.7
7.7
8.7
150.8 138.8
5.6
75
10020.2
32.7
Item Specification
Screw holes for installing PC (VESA compliant) 75 mm x 75 mm
100 mm x 100 mm
Supported PC sizes Within 150 mm x 150 mm x 44 mm
Supported PC weight 0.7 kg or less
