Installing the Wall mount
53
c
Attach it so that the air exhaust vents of the PC are not blocked.
We recommend installing the PC so that the air exhaust vents are at the top and the air intake vents
are at the bottom.
When securing with the mini PC belt
a
Wrap the belt around the mini PC plate
b
Secure the mini PC plate to the wall plate using the M3 x 6 mm screws (x4) supplied.
To Next Page
