Epson LQ-590 - Front Sheet Guide and Front Paper Guide

Options and Consumables 191
6
6
6
6
6
6
6
6
6
6
6
6
It is best to select the paper path in your application program
because software settings usually override the printer’s control
panel settings. However, if you cannot select the paper path in
your application, select a path by pressing the Tear Off/Bin button
until the light indicates the bin you want as shown below.
O=On N=Off F=Flashing
The cut-sheet feeder you selected automatically loads paper when
the printer receives data.
Front Sheet Guide and Front Paper Guide
The optional front sheet guide (C81401✽ for LQ-2090) and front
paper guide (C81402✽ for LQ-590) fit inside the front of the
printer. These guides allow you to load single sheets and
carbonless single-sheet multipart forms of up to 5 parts (one
original and four copies). Paper used with the front guides must
be 148 to 257 mm (5.8 to 10.1 inches) wide and can only be loaded
one sheet at a time.
