Product Information 221
A
A
A
A
A
A
A
A
A
A
A
A
Continuous paper (ordinary and multipart):
Note:
❏ Do not load thick paper, such as multipart forms with five parts, in
the rear slot.
❏ The ratio of the cut/uncut length at the perforation should be
between 3:1 and 5:1.
❏ The thickness of the perforation part when extended should be 1mm
or less.
❏ The perforation between pages should not extend all the way to the
edges of the paper. Uncut length on the edges should be 1mm or
more.
❏ The horizontal and vertical perforation cuts should not cross.
Minimum Maximum
Width LQ-590: LQ-2090:
(mm)
(inch)
101.6
4.0
254.0
10.0
406.4
16.0
Length, one page (mm)
(inch)
101.6
4.0
558.8
22.0
Copies 1 original + 4 copies
Total thickness (mm)
(inch)
0.065
0.0025
0.39
0.015
Weight,
ordinary paper
(g/m²)
(lb)
52
14
82
22
Weight,
per sheet of multipart
(g/m²)
(lb)
40
12
58
15
Quality Plain paper, recycled paper, and
carbonless multipart forms with point
gluing or paper stapling on both sides
To Next Page
