Paper Handling 19
2
2
2
2
2
2
2
2
2
2
2
2
4. Release the left and right sprockets by pushing the blue
sprocket lock levers backward.
5. Slide the left sprocket approximately 12 mm (0.5 inch) from
the far left position and pull the blue lever forward to lock it
in place. Then slide the right sprocket to match the width of
your paper, but do not lock it.
10
5
0
approx. 12 mm (0.5 inch)
To Next Page
