Epson LX 300+II Reference Guide

Paper Handling 11
Chapter 1
Paper Handling
Your printer can handle continuous paper in either the push or
the pull position, as well as single sheets and special papers such
as labels and envelopes.
For instructions on using continuous paper, see the following
section. To load single sheets, see page 26. For information about
special paper, see page 29.
Printing on Continuous Paper
You can print on continuous paper using the tractor in either the
push or pull position:
❏ Use the tractor in the push position if you want to be able to
switch between printing on single sheets and continuous
paper without removing the paper supply, or if you will be
tearing off continuous paper sheet-by-sheet. (Follow the
instructions in the next section.) The printer comes with the
tractor installed in the push position.
❏ Use the tractor in the pull position if you will be printing on
labels, multipart forms, or other documents that require a
precise print position. (See “Printing with the pull tractor”
on page 17 for instructions.)

Epson LX 300+II Specifications

Power

rated voltage	120V AC
input voltage range	99 to 132V, 198 to 164V
rated frequency range	50 to 60 Hz
input frequency range	49.5 to 60.5 Hz
power consumption	Approx. 23W (ISO/IEC 10561 Letter Pattern)

Performance

print speed high speed draft	337 cps (12 cpi)
print speed draft	225 cps (10 cpi)
print speed near letter quality	56 cps (10 cpi)
sound level	49 dBA (ISO 7779 pattern)
mtbf	6, 000 POH (25% duty cycle)
print head life	400 million characters
ribbon life	3 million characters (draft, 10 cpi, 14 dots/character)

Weight and Dimensions

carton dimensions	14.5" x 17.6" x 8.6" (W x D x H)
carton weight	12.10 lb
height	6.26" (159 mm)
width	14.42" (366 mm)
depth	10.84" (275 mm)
weight	9.7 lb (4.4 kg)
