Epson LX 300+II Reference Guide

110 Options and Consumables
Optional Tractor
You can purchase an additional tractor (C800301) and improve
the performance of continuous paper handling by using two
tractors at the same time. This is especially useful with
continuous pre-printed forms and multipart forms.
Follow these steps to install and load paper on the standard and
optional tractor:
1. Turn off the printer.
2. Remove the printer cover and paper guide.
3. Pull the paper release lever forward to the continuous-paper
position.
4. Install the first tractor in the push-tractor position.
5. Remove the paper tension unit by squeezing its lock tabs
gently and pulling it away from the printer.
6. Lower the pull tractor into the mounting slots at the top of
the printer as shown below, until it clicks in place.
7. Load continuous paper on the push tractor.

Epson LX 300+II Specifications

Power

rated voltage	120V AC
input voltage range	99 to 132V, 198 to 164V
rated frequency range	50 to 60 Hz
input frequency range	49.5 to 60.5 Hz
power consumption	Approx. 23W (ISO/IEC 10561 Letter Pattern)

Performance

print speed high speed draft	337 cps (12 cpi)
print speed draft	225 cps (10 cpi)
print speed near letter quality	56 cps (10 cpi)
sound level	49 dBA (ISO 7779 pattern)
mtbf	6, 000 POH (25% duty cycle)
print head life	400 million characters
ribbon life	3 million characters (draft, 10 cpi, 14 dots/character)

Weight and Dimensions

carton dimensions	14.5" x 17.6" x 8.6" (W x D x H)
carton weight	12.10 lb
height	6.26" (159 mm)
width	14.42" (366 mm)
depth	10.84" (275 mm)
weight	9.7 lb (4.4 kg)
