Epson LX 300+II Reference Guide

82 Maintenance and Troubleshooting
Chapter 4
Maintenance and Troubleshooting
This chapter explains how to clean and transport the printer,
and provides basic troubleshooting information.
Cleaning the Printer
To keep your printer operating at its best, you should clean it
thoroughly several times a year. Follow these steps:
1. Remove any paper loaded in the printer and turn it off.
2. Remove the paper guide. If a pull tractor or an optional cut-
sheet feeder is installed, remove it.
3. Use a soft brush to carefully brush away all dust and dirt
from the outer case and paper guide.
4. If the outer case or paper guide is still dirty or dusty, clean
them with a soft, clean cloth dampened with a mild
detergent dissolved in water. Keep the printer cover in place
and lower it until it lies flat on the top of the printer to
prevent water from getting inside the printer.

Epson LX 300+II Specifications

Power

rated voltage	120V AC
input voltage range	99 to 132V, 198 to 164V
rated frequency range	50 to 60 Hz
input frequency range	49.5 to 60.5 Hz
power consumption	Approx. 23W (ISO/IEC 10561 Letter Pattern)

Performance

print speed high speed draft	337 cps (12 cpi)
print speed draft	225 cps (10 cpi)
print speed near letter quality	56 cps (10 cpi)
sound level	49 dBA (ISO 7779 pattern)
mtbf	6, 000 POH (25% duty cycle)
print head life	400 million characters
ribbon life	3 million characters (draft, 10 cpi, 14 dots/character)

Weight and Dimensions

carton dimensions	14.5" x 17.6" x 8.6" (W x D x H)
carton weight	12.10 lb
height	6.26" (159 mm)
width	14.42" (366 mm)
depth	10.84" (275 mm)
weight	9.7 lb (4.4 kg)
