Epson LX 300+II Reference Guide

Using the Printer Software 45
You see the following printer status window:
Note:
It might not be possible to retrieve the printer status during printing.
In this situation, click the EPSON Status Monitor3 button in the
Utility tab, and use the printer with the status window left open.
Installing EPSON Status Monitor 3
To install Status Monitor 3, you can either download it from
Epson’s web site or load it from the Printer Software CD-ROM.
Follow these steps:
1. Make sure the printer is off and Windows is running on
your computer.
2. Insert the Printer Software CD-ROM.
Note:
If the language selection window appears, select your country. If the
EPSON Installation Program screen does not appear automatically,
double-click the My Computer icon, right-click the CD-ROM icon,
click OPEN in the menu, then double-click Epsetup.exe.
3. Click Continue. When the software license agreement
screen appears, read the statement, then click Agree.
4. Click Custom.
5. Select the EPSON Status Monitor 3 check box, then click
Install.

Epson LX 300+II Specifications

Power

rated voltage	120V AC
input voltage range	99 to 132V, 198 to 164V
rated frequency range	50 to 60 Hz
input frequency range	49.5 to 60.5 Hz
power consumption	Approx. 23W (ISO/IEC 10561 Letter Pattern)

Performance

print speed high speed draft	337 cps (12 cpi)
print speed draft	225 cps (10 cpi)
print speed near letter quality	56 cps (10 cpi)
sound level	49 dBA (ISO 7779 pattern)
mtbf	6, 000 POH (25% duty cycle)
print head life	400 million characters
ribbon life	3 million characters (draft, 10 cpi, 14 dots/character)

Weight and Dimensions

carton dimensions	14.5" x 17.6" x 8.6" (W x D x H)
carton weight	12.10 lb
height	6.26" (159 mm)
width	14.42" (366 mm)
depth	10.84" (275 mm)
weight	9.7 lb (4.4 kg)
