106 Options and Consumables
Chapter 5
Options and Consumables
The following options are available for your LX-300+II:
❏ Single-bin cut-sheet feeder (C806371)
❏ Additional tractor (C800301)
❏ Roll paper holder (#8310)
❏ Black ribbon cartridge (#8750)
Cut-sheet Feeder
The optional single-bin cut-sheet feeder (C806371) handles up to
50 sheets of standard bond paper (22 lb or 82 g/m²) without
reloading.
Follow these steps to install the cut-sheet feeder:
1. Make sure the printer is turned off. Remove the paper guide
and open the printer cover.
2. If the tractor is installed in the pull-tractor position, remove
it and reinstall it in the push-tractor position.
3. Make sure the paper release lever is in the single-sheet
position.
