Epson LX 300+II Reference Guide

Using the Control Panel 75
Changing the Default Settings
The default settings control many printer functions. While you
can often set these functions through your software or printer
driver, you may sometimes need to change a default setting
from the printer’s control panel using the Default Setting mode.
The following table lists the default settings and the options you
can select in Default Setting mode. The settings are explained in
detail after the table. For instructions on using Default Setting
mode, see page 80.
Settings Options
Page length for tractor Length in inches: 3, 3.5, 4, 5.5, 6, 7, 8, 8.5, 11,
70/6, 12, 14, 17
Skip over perforation On, Off
Auto tear off On, Off
Auto line feed On, Off
Print direction Bi-D, Uni-D
Software ESC/P, IBM 2380 Plus
0 slash On, Off
High speed draft On, Off
I/F mode Auto, Parallel, Serial, USB
Auto I/F wait time 10 seconds, 30 seconds
Baud rate 19200, 9600, 4800, 2400, 1200, 600, 300 BPS
Parity None, Odd, Even, Ignore
Data length 8 bit, 7 bit
Parallel I/F bidirectional
mode
On, Off
Packet mode Auto, Off

Epson LX 300+II Specifications

Power

rated voltage	120V AC
input voltage range	99 to 132V, 198 to 164V
rated frequency range	50 to 60 Hz
input frequency range	49.5 to 60.5 Hz
power consumption	Approx. 23W (ISO/IEC 10561 Letter Pattern)

Performance

print speed high speed draft	337 cps (12 cpi)
print speed draft	225 cps (10 cpi)
print speed near letter quality	56 cps (10 cpi)
sound level	49 dBA (ISO 7779 pattern)
mtbf	6, 000 POH (25% duty cycle)
print head life	400 million characters
ribbon life	3 million characters (draft, 10 cpi, 14 dots/character)

Weight and Dimensions

carton dimensions	14.5" x 17.6" x 8.6" (W x D x H)
carton weight	12.10 lb
height	6.26" (159 mm)
width	14.42" (366 mm)
depth	10.84" (275 mm)
weight	9.7 lb (4.4 kg)
