Epson LX 300+II Reference Guide

44 Using the Printer Software
3. The following settings are available:
Note:
Click the Default button to restore all items to their default
settings.
If the server’s OS is Windows Vista, select Run as
Administrator to open the printer properties before checking.
Accessing EPSON Status Monitor 3
Do either of the following to access EPSON Status Monitor 3:
❏ Double-click the printer shortcut icon in the taskbar. (To add
a shortcut icon, go to the Utility menu and follow the
instructions.)
❏ Open the Utility menu and click the EPSON Status
Monitor 3 icon.
Setting Explanation
Select Notification Click the Error and Communication Error check
boxes to turn notification on or off.
Select Shortcut Icon The selected icon is displayed in the taskbar
(shown in the example box). Click the Shortcut
Icon check box for easy access to the
Monitoring Preferences window.
Receive error
notification for
shared printers
When this box is checked, you’ll receive
notification of an error on a shared printer.
Allows monitoring
of shared printers
When this box is checked, a shared printer can
be monitored by other PCs.

Epson LX 300+II Specifications

Power

rated voltage	120V AC
input voltage range	99 to 132V, 198 to 164V
rated frequency range	50 to 60 Hz
input frequency range	49.5 to 60.5 Hz
power consumption	Approx. 23W (ISO/IEC 10561 Letter Pattern)

Performance

print speed high speed draft	337 cps (12 cpi)
print speed draft	225 cps (10 cpi)
print speed near letter quality	56 cps (10 cpi)
sound level	49 dBA (ISO 7779 pattern)
mtbf	6, 000 POH (25% duty cycle)
print head life	400 million characters
ribbon life	3 million characters (draft, 10 cpi, 14 dots/character)

Weight and Dimensions

carton dimensions	14.5" x 17.6" x 8.6" (W x D x H)
carton weight	12.10 lb
height	6.26" (159 mm)
width	14.42" (366 mm)
depth	10.84" (275 mm)
weight	9.7 lb (4.4 kg)
