Epson LX 300+II Reference Guide

Maintenance and Troubleshooting 83
c
Caution:
❏ Never use alcohols or thinners to clean the printer; these
chemicals can damage the printer components and the case.
❏ Be careful not to get water onto the printer mechanism or
electronic components.
❏ Do not use a hard or abrasive brush.
❏ Do not spray the inside of the printer with lubricants;
unsuitable lubricants can damage the printer mechanism.
Transporting the Printer
If you need to transport your printer for some distance, carefully
repack it using the original box and packing materials or
equivalent packaging.
w
Warning:
❏ When transporting the printer, do not lift it by the USB cable
holder as the holder may detach and cause the printer to fall.
Hold the bottom left and right sides of the printer firmly to
lift it.
❏ You need to move the print head by hand to remove the ribbon
cartridge. If you have just used the printer, the print head
may be hot; let it cool for a few minutes before touching it.
1. Remove any paper loaded in the printer. Make sure the
printer is turned off.
2. Unplug the power cord from the electrical outlet; then
disconnect the interface cable from the printer.
3. Remove the paper guide, the USB cable holder, paper
supports, and knob.

Epson LX 300+II Specifications

Power

rated voltage	120V AC
input voltage range	99 to 132V, 198 to 164V
rated frequency range	50 to 60 Hz
input frequency range	49.5 to 60.5 Hz
power consumption	Approx. 23W (ISO/IEC 10561 Letter Pattern)

Performance

print speed high speed draft	337 cps (12 cpi)
print speed draft	225 cps (10 cpi)
print speed near letter quality	56 cps (10 cpi)
sound level	49 dBA (ISO 7779 pattern)
mtbf	6, 000 POH (25% duty cycle)
print head life	400 million characters
ribbon life	3 million characters (draft, 10 cpi, 14 dots/character)

Weight and Dimensions

carton dimensions	14.5" x 17.6" x 8.6" (W x D x H)
carton weight	12.10 lb
height	6.26" (159 mm)
width	14.42" (366 mm)
depth	10.84" (275 mm)
weight	9.7 lb (4.4 kg)
