Epson LX 300+II Reference Guide

22 Paper Handling
Adjusting the top-of-form position
The top-of-form position is the position on the page where the
printer starts printing. If your printing appears too high or too
low on the page, you can use the Micro Adjust mode to adjust
the top-of-form position.
c
Caution:
Never use the paper feed knob to adjust the top-of-form position;
this may damage the printer or cause it to lose the top-of-form
position.
1. Make sure the printer is turned on and paper is loaded.
2. Remove the printer cover.
3. Hold down the Pause button for about three seconds. The
printer beeps and the Pause light starts flashing as the
printer enters Micro Adjust mode.
4. Press the LF/FF D button to move the top-of-form position
higher on the page, or press the Load/Eject U button to
move the top-of-form position lower on the page.

Epson LX 300+II Specifications

Power

rated voltage	120V AC
input voltage range	99 to 132V, 198 to 164V
rated frequency range	50 to 60 Hz
input frequency range	49.5 to 60.5 Hz
power consumption	Approx. 23W (ISO/IEC 10561 Letter Pattern)

Performance

print speed high speed draft	337 cps (12 cpi)
print speed draft	225 cps (10 cpi)
print speed near letter quality	56 cps (10 cpi)
sound level	49 dBA (ISO 7779 pattern)
mtbf	6, 000 POH (25% duty cycle)
print head life	400 million characters
ribbon life	3 million characters (draft, 10 cpi, 14 dots/character)

Weight and Dimensions

carton dimensions	14.5" x 17.6" x 8.6" (W x D x H)
carton weight	12.10 lb
height	6.26" (159 mm)
width	14.42" (366 mm)
depth	10.84" (275 mm)
weight	9.7 lb (4.4 kg)
