Epson LX 300+II Reference Guide

84 Maintenance and Troubleshooting
4. Make sure the tractor that comes with your printer is
installed in the push position.
5. If an additional pull tractor is installed, remove it. If any
options are installed, remove them and pack them in their
original boxes.
6. Make sure the print head is not hot. Then remove the ribbon
cartridge.
7. Repack the printer and all the other items in their original
packing materials and place them in the printer’s original
box.
Troubleshooting
You can solve most printing problems by checking for the
solutions in this section. It explains:
❏ How to read the control panel lights that indicate errors
(page 85)
❏ Problems and solutions (page 87)
❏ Clearing paper jams (page 101)
❏ Printing a self test (page 102)
❏ Where to get help if you need assistance from Epson
(page 104)

Epson LX 300+II Specifications

Power

rated voltage	120V AC
input voltage range	99 to 132V, 198 to 164V
rated frequency range	50 to 60 Hz
input frequency range	49.5 to 60.5 Hz
power consumption	Approx. 23W (ISO/IEC 10561 Letter Pattern)

Performance

print speed high speed draft	337 cps (12 cpi)
print speed draft	225 cps (10 cpi)
print speed near letter quality	56 cps (10 cpi)
sound level	49 dBA (ISO 7779 pattern)
mtbf	6, 000 POH (25% duty cycle)
print head life	400 million characters
ribbon life	3 million characters (draft, 10 cpi, 14 dots/character)

Weight and Dimensions

carton dimensions	14.5" x 17.6" x 8.6" (W x D x H)
carton weight	12.10 lb
height	6.26" (159 mm)
width	14.42" (366 mm)
depth	10.84" (275 mm)
weight	9.7 lb (4.4 kg)
