Epson LX 300+II Reference Guide

Maintenance and Troubleshooting 85
Using the error indicators
If your printer stops working and one or more control panel
lights are on or flashing or the printer beeps, use the following
table to diagnose and fix the problem. If you cannot fix your
problem using this table, go to the next section.
Panel light
state
Beep
pattern
Problem
Solution
n Pause – The printer is paused.
Press the Pause button to resume printing.
••• Paper from another paper source is
currently in the paper path.
Move the paper release lever to the
correct position and press the Load/Eject
button to clear the paper from the paper
path. Then set the lever to the position
you want to use. Press the Pause button to
turn off the Pause light, if necessary.
n Paper Out
n Pause
••• No paper is loaded in the selected paper
source.
Load paper in the printer. Then press the
Pause button to turn off the Pause light, if
necessary.
••• The paper is not loaded correctly.
Remove your paper and reload it. Then
press the Pause button to turn off the
Pause light, if necessary.
••• Paper is jammed in the printer.
Turn off the printer and open the printer
cover, tear off the paper supply, and turn
the paper feed knob to eject the
remaining paper.

Epson LX 300+II Specifications

Power

rated voltage	120V AC
input voltage range	99 to 132V, 198 to 164V
rated frequency range	50 to 60 Hz
input frequency range	49.5 to 60.5 Hz
power consumption	Approx. 23W (ISO/IEC 10561 Letter Pattern)

Performance

print speed high speed draft	337 cps (12 cpi)
print speed draft	225 cps (10 cpi)
print speed near letter quality	56 cps (10 cpi)
sound level	49 dBA (ISO 7779 pattern)
mtbf	6, 000 POH (25% duty cycle)
print head life	400 million characters
ribbon life	3 million characters (draft, 10 cpi, 14 dots/character)

Weight and Dimensions

carton dimensions	14.5" x 17.6" x 8.6" (W x D x H)
carton weight	12.10 lb
height	6.26" (159 mm)
width	14.42" (366 mm)
depth	10.84" (275 mm)
weight	9.7 lb (4.4 kg)
