Epson LX 300+II Reference Guide

20 Paper Handling
9. Slide the left sprocket so its pins are aligned with the holes in
the paper and push the blue lock lever to lock the sprocket in
place. Then slide the right sprocket to match the width of
your paper, but do not lock it. Move the paper supports
midway between the two sprockets.
10. Make sure your paper has a clean, straight leading edge.
Open the sprocket covers. Fit the first holes of the paper over
the sprocket pins and then close the sprocket covers. Slide
the right sprocket to remove any slack in the paper and then
lock it in place.
Note:
Remove any remaining slack by gently pulling the paper from the
back.

Epson LX 300+II Specifications

Power

rated voltage	120V AC
input voltage range	99 to 132V, 198 to 164V
rated frequency range	50 to 60 Hz
input frequency range	49.5 to 60.5 Hz
power consumption	Approx. 23W (ISO/IEC 10561 Letter Pattern)

Performance

print speed high speed draft	337 cps (12 cpi)
print speed draft	225 cps (10 cpi)
print speed near letter quality	56 cps (10 cpi)
sound level	49 dBA (ISO 7779 pattern)
mtbf	6, 000 POH (25% duty cycle)
print head life	400 million characters
ribbon life	3 million characters (draft, 10 cpi, 14 dots/character)

Weight and Dimensions

carton dimensions	14.5" x 17.6" x 8.6" (W x D x H)
carton weight	12.10 lb
height	6.26" (159 mm)
width	14.42" (366 mm)
depth	10.84" (275 mm)
weight	9.7 lb (4.4 kg)
