Epson LX 300+II Reference Guide

64 Using the Printer Software
The folder name depends on which operating system is
being used.
3. Select the name of the printer, and click OK. Then follow the
on-screen instructions.
Note:
❏ If you also want to install EPSON Status Monitor 3, see page 45
for instructions.
❏ To use EPSON Status Monitor 3 for the shared printer, reinstall
the printer driver as instructed in “Setting up the clients” after
installing the printer driver and EPSON Status Monitor 3 from
the CD-ROM. Before printing, be sure to select the printer driver
installed in “Setting up the clients” on page 50.
❏ If EPSON Status Monitor 3 is installed with the Windows
Firewall feature turned on (recommended), the shared printer may
not be able to be monitored. If this occurs, follow the steps below to
enable monitoring.
1. Add EPSON Status Monitor 3 to the Windows Firewall Exceptions list.
For Windows XP:
Click Start > Control Panel > Security Center, and then click
Windows Firewall.
Client’s OS Folder Name
Windows 98 \<Language>\WIN98
Windows Me \<Language>\WINME
Windows 2000 or XP \<Language>\WIN2000
Windows Vista x86 Edition \<Language>\WINVISTA
Windows XP Professional x64
Edition, Vista x64 Edition
\<Language>\WINVISTA_XP64
Windows NT 4.0 \<Language>\WINNT40

Epson LX 300+II Specifications

Power

rated voltage	120V AC
input voltage range	99 to 132V, 198 to 164V
rated frequency range	50 to 60 Hz
input frequency range	49.5 to 60.5 Hz
power consumption	Approx. 23W (ISO/IEC 10561 Letter Pattern)

Performance

print speed high speed draft	337 cps (12 cpi)
print speed draft	225 cps (10 cpi)
print speed near letter quality	56 cps (10 cpi)
sound level	49 dBA (ISO 7779 pattern)
mtbf	6, 000 POH (25% duty cycle)
print head life	400 million characters
ribbon life	3 million characters (draft, 10 cpi, 14 dots/character)

Weight and Dimensions

carton dimensions	14.5" x 17.6" x 8.6" (W x D x H)
carton weight	12.10 lb
height	6.26" (159 mm)
width	14.42" (366 mm)
depth	10.84" (275 mm)
weight	9.7 lb (4.4 kg)
