Epson LX 300+II Reference Guide

Maintenance and Troubleshooting 95
Options
When you use the cut-sheet feeder, the paper does not feed
properly
When you switch between single sheets and continuous
paper, the printer beeps three times and the PAUSE light
comes on.
Cause What to do
You may have tried to
change the paper release
lever position while paper
remained in the printer.
Return the paper release lever to the
previous position and eject the paper.
Then change the paper release lever
position.
The paper does not feed.
Cause What to do
The cut-sheet feeder may
be incorrectly installed.
Reinstall it as described on page 98.
The paper release lever
may be in the wrong
position.
Check that the paper release lever is
pushed back to the single-sheet position.
You may have loaded too
many sheets in the bin.
Remove some sheets.
Paper may be jammed near
the print head.
Look for a paper jam.
The edge guide positions
may be incorrect.
Position the edge guides at the diamond-
shaped guide marks.
There may be only one
sheet left in the bin.
Add more paper.

Epson LX 300+II Specifications

Power

rated voltage	120V AC
input voltage range	99 to 132V, 198 to 164V
rated frequency range	50 to 60 Hz
input frequency range	49.5 to 60.5 Hz
power consumption	Approx. 23W (ISO/IEC 10561 Letter Pattern)

Performance

print speed high speed draft	337 cps (12 cpi)
print speed draft	225 cps (10 cpi)
print speed near letter quality	56 cps (10 cpi)
sound level	49 dBA (ISO 7779 pattern)
mtbf	6, 000 POH (25% duty cycle)
print head life	400 million characters
ribbon life	3 million characters (draft, 10 cpi, 14 dots/character)

Weight and Dimensions

carton dimensions	14.5" x 17.6" x 8.6" (W x D x H)
carton weight	12.10 lb
height	6.26" (159 mm)
width	14.42" (366 mm)
depth	10.84" (275 mm)
weight	9.7 lb (4.4 kg)
