130
For PP-100/PP-50
1
Turn the product off.
See “Turning Off the Power” on page 20.
2
After the Power light goes off, unplug the power plug from the outlet.
3
Remove the two screws to remove the rear printer cover.
If the disc can be removed, eject the disc and reattach the rear printer cover. If the disc cannot be removed,
proceed to the procedure below.
4
Grasp the fixture as shown in the figure below, and push the printer tray in the direction of
the arrow indicated below.
5
Open the disc cover.
To Next Page
