SC-S30600 Series Revision B
DISASSEMBLY & ASSEMBLY Disassembly and Assembly Procedure 131
Confidential
Make sure to attach the CR Scale to the CR Scale Holder as
shown.
Make sure the CR Scale can run through the slit of the CR
Encoder.
CR Scale Holder
CR Scale
Rouge the scale
behind these portions
CR Scale
CR Encoder
