SC-S30600 Series Revision B
MAINTENANCE Cleaning 287
Confidential
7. Wipe the outer surfaces of the four caps with a Cleaning swab.
Figure 5-14. Cleaning the Cap
8. Press the OK button.
The wiper moves toward the rear.
9. Remove the wiper cleaner.
10. Using a cleaning swab moistened with Ink cleaner, clean the wiper rail.
Figure 5-15. Cleaning the Wiper Rail
11. Attach the wiper cleaner.
12. Close the Maintenance cover. Press the OK button to finish cleaning. (The Print
Head goes back to the Home Position)
Do not touch the inner part of the caps.
To Next Page
