Epson SC-S30600 Series User Manual

SC-S30600 Series Revision B
TROUBLE SHOOTING Remedies for Service Call Error 42
Confidential
151D
APG Motor
driving time-out error
Abnormally-long driving duration of the APG Motor
was detected.
 Irregular load
 Firmware becomes out of control.
---
Replace the Main Board. (Page 107)
151E
APG Motor
velocity deviation error
The APG Motor was driven at a speed abnormally
faster than a predetermined one during acceleration or
deceleration.
 Irregular load
 APG encoder failure
 APG Motor failure
 APG Motor driver failure
---
1. Replace the APG Motor. (Page 138)
2. Replace the Main Board. (Page 107)
151F
APG Motor
lock error
 Connection failure of the APG Motor.
 The APG Motor was driven at a speed abnormally
slower than a predetermined one during operation.
 Irregular load
 APG encoder failure
 APG Motor failure
Is there any problems such as damaged cable in the
connections below?
 APG Motor (APG encoder) to Main Board
(CN210/CN23)
Replace the APG Motor. (Page 138)
1599
ATC Motor
oscillation error
The control terminal (Vre terminal) of the ATC Motor
driver has shorted out.
1. Is the ATC Motor driver on the Main Board
damaged?
2. Is there any foreign materials around the ATC
Motor driver?
1. Remove the foreign material.
2. If the error still occurs, replace the Main Board.
(Page 107)
159A
ATC Motor
overload error
Overcurrent to the ATC Motor was detected.
 ATC Motor cable disconnection.
 Irregular load
 ATC Motor encoder failure
 ATC Motor failure
1. Is there any problems such as damaged cable in the
connections below?
 ATC Motor to Sub-F Board (CN602/CN604)
2. Does the ATC Motor encoder work properly?
Check it using the Service Program.
Replace the ATC Motor. (Page 181)
159B
ATC Motor
over speed error
The ATC Motor was driven at a speed faster than a
predetermined one during deceleration.
 Irregular load
 ATC Motor encoder failure
 Sub-F Board failure
 APG Motor driver failure
Does the ATC Motor encoder work properly? Check
it using the Service Program.
1. Replace the ATC Motor. (Page 181)
2. Replace the Sub-F Board. (Page 179)
3. Replace the Main Board. (Page 107)
159C
ATC Motor
reversing error
The number of occurrences of reversing the ATC
Motor has reached a predetermined limit.
 The polarity of ATC Motor cable is opposite.
 ATC Motor failure
1. Is there any problems such as damaged cable in the
connections below?
 ATC Motor to Sub-F Board (CN602/CN604)
2. Does the ATC Motor encoder work properly?
Check it using the Service Program.
Replace the ATC Motor. (Page 181)
Code Error Name Cause Check Item Remedy
