SC-S30600 Series Revision B
TROUBLE SHOOTING Remedies for Service Call Error 43
Confidential
159D
ATC Motor
driving time-out error
Abnormally-long driving duration of the ATC Motor
was detected.
 Irregular load
 Firmware becomes out of control.
---
Replace the Main Board. (Page 107)
159E
ATC Motor
velocity deviation error
The APG Motor was driven at a speed abnormally
faster than a predetermined one during acceleration or
deceleration.
 Irregular load
 ATC Motor encoder failure
 ATC Motor failure
 Sub-F Board disconnection
 ATC Motor driver failure
Does the ATC Motor encoder work properly? Check
it using the Service Program.
1. Replace the ATC Motor. (Page 181)
2. Replace the Sub-F Board. (Page 179)
3. Replace the Main Board. (Page 107)
159F
ATC Motor
lock error
 Connection failure of the ATC Motor.
 The ATC Motor was driven at a speed abnormally
slower than a predetermined one during operation.
 Irregular load
 ATC Motor encoder failure
 ATC Motor failure
1. Is there any problems such as damaged cable in the
connections below?
 ATC Motor to Sub-F Board (CN602/CN604)
2. Does the ATC Motor encoder work properly?
Check it using the Service Program.
Replace the ATC Motor. (Page 181)
1610
Roll/Reel Units
mismatch error
The combination of the Roll Unit and Reel Unit may
be wrong; one of the units may be an optional unit.
Is the combination of the Roll Unit and Reel Unit
either both of them are standard units or both of them
are optional units?
Correct the combination of the Roll Unit and Reel
Unit to either both are standard or both are optional.
1611
Roll Unit
undetectable error
The Roll Unit could not be detected during
mechanism initialization process.
Is the connector of the Roll Unit disconnected? Connect the connector of the Roll Unit.
1612
Roll Unit
undetectable error at the
start of operation
When the ATC Motor started to operate, it was
detected that the Roll Unit status is different from that
detected during mechanism initialization process.
1. Is the connector of the Roll Unit disconnected?
2. Has the Roll Unit been replaced since the power on
and while the ATC Motor was stopping?
1. Connect the connector of the Roll Unit.
2. Turn the printer off and back on.
1613
Roll Unit
undetectable error
during operation
The connector of the Roll Unit was disconnected
during the ATC Motor was operating.
Is the connector of the Roll Unit disconnected? Connect the connector of the Roll Unit.
1614
Reel Unit
undetectable error at the
start of operation
When the Reel Motor started to operate, it was
detected that the Reel Unit status is different from that
detected during mechanism initialization process.
1. Is the connector of the Reel Unit disconnected?
2. Has the Reel Unit been replaced since the power on
and while the Reel Motor was stopping?
1. Connect the connector of the Reel Unit.
2. Turn the printer off and back on.
1615
Reel Unit
undetectable error
during operation
The connector of the Reel Unit was disconnected
during the Reel Motor was operating.
Is the connector of the Reel Unit disconnected? Connect the connector of the Reel Unit.
1616 Roll Unit Board failure
There is a problem with a specific bit on the board,
which detects what device is connected to the board.
Unexpected error
Replace the Sub-F Board of the Roll Unit. (Page
186)
Code Error Name Cause Check Item Remedy
