TROUBLE SHOOTING Remedies for Service Call Error 44
Confidential
1617 Reel Unit Board failure
There is a problem with a specific bit on the board,
which detects what device is connected to the board.
Unexpected error
Replace the Sub-F Board of the Reel Unit. (Page
186)
1618
Roll/Reel Unit Board
failure
There is a problem with a specific bit on the board,
which detects what device is connected to the board.
Unexpected error
Replace the Sub-F Board of the Roll Unit (Page
179) and Reel Unit (Page 186).
1A23
RTC data
invalid error
The various absolute time settings stored on the
NVRAM are abnormal.
Reset the date and time settings of the RTC using the
Service Program.
If the error still occurs after resetting the date and
time, perform the followings.
1. Replace the RTC backup battery.
2. Replace the Main Board. (Page 107)
1A26
RTC Access
T/O error
The RTC circuit on the Main Board malfunctions.
---
1. Turn the power off and remove the RTC backup
battery.
2. After several seconds, re-attach the battery and
turn the power back on.
3. Reset the date and time settings of the RTC using
the Service Program.
1A37 Thermistor error
 The Head FFC is not connected correctly.
 A temperature out of a predetermined range was
detected by the Head thermistor.
 Head thermistor failure
Is the Head FFC connected properly without being
connected at an angle and any abnormalities such as
ripped terminal cover?
1. Replace the Head FFC. (Page 123)
2. Replace the Print Head. (Page 121)
1A38
Transistor
environmental
temperature error
 Transistor failure
 A temperature out of a predetermined range was
detected by the Head thermistor.
---
Replace the Print Head. (Page 121)
1A39 Head error
 Connection failure of the Head FFC.
 Electric parts or components are damaged due to
improper Head FFC connection such as connecting
it at an angle.
 The drive circuit in the Print Head is damaged.
 The fuse of the Main Board has blown.
Is the Head FFC connected properly without being
connected at an angle and any abnormalities such as
ripped terminal cover?
1. Replace the Head FFC. (Page 123)
2. Replace the Print Head. (Page 121)
3. Replace the Main Board. (Page 107)
1A41
Head rank ID
input error
An invalid Head rank ID was written to the NVRAM. Check the Head rank ID using the Service Program.
Rewrite the Head rank ID with a correct one. (Page
246)
1A50
I2C communication
error between elements
on ASIC and MAIN
An I2C communication error has occurred in the
Main Board.
---
Replace the Main Board. (Page 107)
1A51
I2C communication
error between elements
on ASIC and SUB
An I2C communication error between the Main Board
and Sub Board has occurred.
Are the Main Board and Sub Board properly
connected to each other without any cable
disconnection, FFCs being connected at an angle, and
any abnormalities such as ripped terminal cover?
1. Replace the FFC that connects the Main Board
and Sub Board.
2. Replace the Sub Board. (Page 113)
3. Replace the Main Board. (Page 107)
