SC-S30600 Series Revision B
DISASSEMBLY & ASSEMBLY Disassembly and Assembly Procedure 96
Confidential
8. Holding the Front Cover upright, remove the Left Upper Cover pulling out its joint
part in the direction of the arrow.
Figure 3-31. Removing the Left Upper Cover
Left Upper Cover
Front Cover
Joint part
