Epson Stylus DX4850 Service Manual

EPSON Stylus CX4100/CX4200/CX4700/CX4800/DX4200/DX4800/DX4850 Revision A
PRODUCT DESCRIPTION Memory Card Print (Only for CX4700/CX4800/DX4800/DX4850) 45
1.5.8.3 20-up
Figure 1-21. 20-up
Note *1: 4" x 6" size will be used for Stylus CX4200/CX4800.
*2: 10cm x 15 cm size will be used for Stylus CX4100/CX4700/ DX4200/DX4800/
DX4850.
1.5.8.4 30-up
Figure 1-22. 30-up
Note *1: 4" x 6" size will be used for Stylus CX4200/CX4800.
*2: 10cm x 15 cm size will be used for Stylus CX4100/CX4700/ DX4200/DX4800/
DX4850.
Table 1-42. 20-up (unit: mm (inch))
Paper type A B C D E F G H I J K L
4" x 6" *
1
101.60
(4.00)
152.40
(6.00)
20.00
(0.79)
20.00
(0.79)
6.10
(0.24)
6.30
(0.25)
19.80
(0.78)
20.30
(0.80)
3.00
(0.12)
3.00
(0.12)
89.30
(3.52)
112.30
(4.42)
10cm x 15cm *
2
101.60 152.40 20.00 20.00 6.10 6.30 19.80 20.30 3.00 3.00 89.30 112.30
A
K
L
J
D
EF
G
H
B
J
J
J
C
II
I
Table 1-43. 30-up (unit: mm (inch))
Paper
type
A B C D E F G H I J
5" x 7"*
1
127.00
(5.00)
178.00
(7.00)
20.0
(0.79)
20.0
(0.79)
4.5
(0.18)
4.5
(0.18)
14.0
(0.55)
14.0
(0.55)
4.5
(0.18)
6.0
(0.24)
13 x 18*
2
127.00 128.00 20.0 20.0 4.5 4.5 14.0 14.0 4.5 6.0
D
E
F
G
H
C
B
A
I
J
