Epson Stylus Photo R3000 - Inside; Back

Inside
A Cartridge cover
Open when replacing ink cartridges.
U “Replacing Ink Cartridges” on page 92
B Ink absorber
Absorbs ink that bleeds past the edge of the paper
during borderless printing.
C Print head
Fires ink via high density nozzles while moving left
and right to print. Do not move the print head by
hand.
Back
A AC inlet
Connects the power cable.
B Airflow vents
Prevent the build-up of heat inside the printer.
C USB connector
Connects the USB cable.
D LAN connector
Connects the LAN cable.
E Roll paper feeder
Paper feed slot for roll paper printing.
U “Loading Roll Paper” on page 26
F Rear support
Use when loading fine art media or roll paper.
U “Loading Fine Art Media” on page 22
U “Loading Roll Paper” on page 26
