H
While two pages are overlapping, cut them along
the alignment marks (horizontal red line).
I
Join the upper and lower sheets together.
Use an adhesive tape to stick the backs of the
sheets together.
J
After joining all of the sheets together, cut the
margins along the outer guide lines.
User-defined Paper Sizes/
Custom Paper Sizes
You can also print on paper sizes that are not already
available in the printer driver. User-defined paper sizes
that have created and saved as described below can be
selected using the application page setup option. If your
application supports creating user defined sizes, follow
the steps below to select the same size that was created in
the application, and then print.
See the following for information on the paper sizes
supported by this printer.
U “Usable Commercially Papers” on page 109
In addition, the following paper sizes can be selected for
User Defined Paper Size (Windows) or Custom Paper
Sizes (Mac OS X) in the printer driver.
Note:
❏ Although you can specify a large paper size which
cannot be loaded on this printer, it will not be
printed properly.
❏ The available output size is limited depending on
the application.
Auto sheet feeder/roll paper
1
Width 89.0–329.0 mm
Length
55.0–3276.7 mm
2
Front manual feed (poster board)
3
/front manual
feed (fine art media)
Width 210.0–329.0 mm
Epson Stylus Photo R3000 User's Guide
Printing Varieties
71
