Epson TM-T20III User Manual

32
Chapter 2 Setup
Setting up Using a USB Connection from a Windows Computer
Necessary Items
• Computer for setting: Windows 10/8/7
• Utility for setting: TM-T20III Utility
• USB cable
Follow the steps below to connect the printer.
1
Connect the printer to the computer via the USB cable.
2
Turn on the computer.
3
Turn on the printer.
4
Start the TM-T20III Utility.
5
Select the printer, and then press the [OK] button.
If the printer is not displayed, press the “Add Port” button, and then add the printer connected by
USB.
6
Perform network I/F as well as TCP/IP settings.
For details, see the TM-T20III Utility User's Manual.
7
When you have finished making settings, disconnect the USB cable, turn off the
printer, and then turn it back on.
To start wireless LAN communication, be sure to disconnect the USB cable, turn off the
printer, and then turn it back on.

Epson TM-T20III Specifications

General

Type	POS printer
Character sets	ANK
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum roll diameter	83 mm
Supported paper width	80 mm
USB port	Yes
USB connector	USB Type-B
Standard interfaces	RS-232, USB 2.0
Serial interface type	RS-232
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Mean cycles between failures (MCBF)	60000000
AC input voltage	24 V
Power consumption	1800 mA
Power source type	AC
Power consumption (standby)	100 mA
Product color	Black
Safety	UL, CSA, TÜV
Certification	FCC-Class A, CE, EN55022-Class A
Country of origin	Philippines
Mounting position	Horizontal/Vertical
Autocutter durability	1.5 million cuts
Built-in sensors details	Roll paper cover open sensor, Paper End Sensor, Paper Near End Sensor
Sound pressure level (printing)	55 dB
Mean time between failures (MTBF)	360000 h
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	235 mm
Package width	192 mm
Package height	280 mm
Package weight	2620 g
Quantity per pack	1 pc(s)
Ethernet LAN	No
Quantity per pallet	112 pc(s)
Quantity per pallet (UK)	168 pc(s)
Master (outer) case width	400 mm
Quantity per pallet layer	16 pc(s)
Master (outer) case height	295 mm
Master (outer) case length	490 mm
Master (outer) case weight	0 g
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	24 pc(s)
Quantity per master (outer) case	4 pc(s)

Weight and Dimensions

Depth	199 mm
Width	140 mm
Height	146 mm
