Epson TM-T88VI Technical Reference Guide

123
Appendix
Wi-Fi Interface
Specification
 IEEE802.11b/g/n (2.4 GHz band) or IEEE802.11a/b/g/n (2.4 GHz or 5 GHz band) compliant
Wi-Fi communication compatible.
 Infrastructure mode and 802.11 Ad-hoc mode are supported.
Communication Standard
When using OT-WL02:
 IEEE802.11b (2.4 GHz)
 IEEE802.11g (2.4 GHz)
 IEEE802.11n (2.4 GHz)
When using OT-WL05:
 IEEE802.11b (2.4 GHz)
 IEEE802.11g (2.4 GHz)
 IEEE802.11n (2.4 GHz)
 IEEE802.11a (5 GHz)
 IEEE802.11n (5 GHz)
Security
Security can be selected from among the following:
 WEP
 WPA-PSK(AES): WPA-PSK(AES),WPA-PSK(TKIP),WPA2-PSK(AES),WPA2-PSK(TKIP) can be connected
 WPA2-PSK: WPA2-PSK(AES),WPA2-PSK(TKIP) can be connected
 WPA2-Enterprise
Settings in SimpleAP mode (Factory default settings)
* In SimpleAP mode, DHCP Server is working and assigns IP address to host automatically.
 Countries where Wi-Fi can be used are limited. Since notes are provided for each country, check the
sheet supplied with the product.
 When using wireless LAN, make sure you disconnect the LAN cable. If a LAN cable is connected,
wireless LAN is disabled.
Parameter Setting value
SSID EPSON_Printer
Passphrase 12345678
IP Address 192.168.192.168
Subnet mask 255.255.255.0

Epson TM-T88VI Specifications

General

Type	POS printer
Print technology	Thermal
Maximum resolution	180 x 180 DPI
Cutter	Yes
Safety	UL60950-1/CSA C22.2 No.60950-1
Built-in barcodes	AZTECCODE, Code 39, Code 93, Code-128 Codabar Library, Data Matrix, GS1 DataBar, GS1 DataBar Limited, GS1-128, MaxiCode, PDF417, UPC-A, UPC-E
Autocutter durability	3 million cuts
Mean time between failures (MTBF)	360000 h
Maximum roll diameter	83 mm
Supported paper width	57.50/79.5 mm
Bluetooth version	2.1+EDR
Standard interfaces	Bluetooth, Ethernet, Parallel, Serial, USB
Connectivity technology	Wired & Wireless
Electromagnetic compatibility	FCC/ICES-003 Class A
Mean cycles between failures (MCBF)	70000000
Product color	Black

Weight and Dimensions

Depth	195 mm
Width	145 mm
Height	148 mm
