Chapter 2 Setup
2
Setting the Built-in Buzzer
(for Model with a Built-in Buzzer)
For specifications with a built-in buzzer, a pulse output is sent to drawer kick connector pin 5 to beep the
buzzer.
When using a cash drawer, connect a cash drawer operated by pin 2.
If you have to use a cash drawer operated by pin 5, change the DIP switch settings for the buzzer circuit.
For details, see
"Setting the DIP Switches" - "Setting Procedure" on page 55.
DIP Switch for Buzzer Circuit
DIP
switch
Specified connector pin ON OFF
Default
setting
1 Drawer kick connector pin 2 Buzzer beeps. Buzzer does not
beep.
ON
2 Drawer kick connector pin 5 Buzzer beeps. Buzzer does not
beep.
OFF
Do not set the buzzer to beep for pin numbers used for drawer operations. The buzzer and the
cash drawer cannot be operated by one pulse signal.
