Starting and stopping Bluetooth low energy technology Advertising
Format: cmd 0x08 0x000A n
Function: Starting and stopping transmission of the Advertising packet.
Device address specifications
Format: cmd 0x08 0x0005 n6 n5 n4 n3 n2 n1
Function: Specify a BD Address. Specify a value in Little Endian.
Bluetooth low energy technology Advertising parameter specifications
Format: cmd 0x08 0x0006 aL aH bL bH c d e f1 f2 f3 f4 f5 f6 g h
Function: Sets a variety of parameters for the Advertising packet.
See the Bluetooth specifications for details.
Parameter n Length Function
00 2 characters Advertising stop
01 2 characters Advertising start
When specifying a start point, make sure you start Advertising using this command before
"Bluetooth
low energy technology Advertising Packet specifications" on page 144
.
As a Random Static Address is used in T88VI, bit7 and bit6 for n1 need to be set to 1.
Definition Length Default Description
Min advertising Interval 2 bytes aL: a0
aH: 00
00a0h * 0.625 = 100ms Period
00a0h is the minimum that can be
specified.
Max advertising Interval 2 bytes bL: a0
bH: 00
00a0h * 0.625 = 100ms Period
00a0h is the minimum that can be
specified.
Advertising type 1 bytes c: 03 03h: ADD_NONCONN_IND
Own address type 1 bytes d: 01 01h: random device address
Peer address type 1 bytes e: 00 00h: public device address
Peer address 6 bytes f1-f6: 00 No use
Advertising channel map 1 bytes g: 07 07h: All channel enabled
Advertising filter policy 1 bytes h: 02 02h: Process scan requests from all
devices and only connection requests
from devices that are in the White List.
