Rev. A Setup 3-1
TM-U220II Technical Reference Guide
Chapter 3
Setup
3.1 Part Name and Basic Operation
3.1.1 Part name
3.1.1.1 Connectors
WARNING:
Do not connect a telephone line to the drawer kick connector or the display module connector;
otherwise the printer and the telephone line may be damaged.
Do not insert a Type-B USB connector into the LAN connector or drawer kick connector. Inserting
such a connector may damage the connector, printer, or system.
This figure is Type A.
unit (Type A only)
ribbon casette cover
power switch
roll paper cover
manual cutter
control panel
