Rev. A Setup 3-9
TM-U220II Technical Reference Guide
3.3.2.2 Installing the Roll Paper for Type A
1. Using scissors, cut the leading edge of
the roll paper, as shown in the left figure.
2. Turn on the printer and open the roll
paper cover by using the tab, as shown in
the left.
Note:
The printer feeds for 30 mm automatically if
the roll paper cover is open. This is a normal
operation to prevent the printer from
damaging the paper when the roll paper cover
is opened or closed.
Since the printer does not feed even if the roll
paper cover is open when the printer is
turned off, make sure not to pinch the paper
when the cover is closed.
3. Open the unit by using the lever, as
shown in the left.
To Next Page
