6-2 Notices for Replacement of the TM-U210/TM-U220/TM-U300 Rev. A
6.1.1.2 Characters
The TM-U220II has nearly the same character specifications as the TM-U210. Additionally, the
TM-U220II and TM-U220 have the same character specifications. Therefore, the TM-U220II can
print same contents as the TM-U210/TM-U220 without any adjustment of settings.
Note:
The characters per line (cpl) for fonts A and B can changed by DIP SW2-1.
The cpl for the kanji font can be changed by ESC/POS command (default: 22 cpl).
6.1.1.3 Cutting distance from print start position
The TM-U220II has the same distance between the auto cut position and print start position as
the TM-U210/TM-U220. Therefore, the top margin remains the same when the TM-U210/TM-
U220 is replaced with the TM-U220II with autocutter. In other cases, please refer to the table and
figures below.
Character specifications TM-U210 (Type A, B, and D) TM-U220/TM-U220II (Type A, B, and D)
Characters
per line
(cpl)
Font A (9 x 9) 33 (35) cpl 33 (35) cpl
Font B (7 x 9) 40 (42) cpl 40 (42) cpl
Kanji (16 x 16) 22 (25) cpl 22 (25) cpl
Character
width
Font A (9 x 9) 1.6 x 3.1 1.6 x 3.1
Font B (7 x 9) 1.2 x 3.1 1.2 x 3.1
Kanji (16 x 16) 2.7 x 2.7 2.7 x 2.7
Character configuration Code page 0 to 8 and 19 to
26
Code page 0 to 8 and 19 to 26, and code
page 16, 17, and 18
Cutting position TM-U210 (Type A, B, and D) TM-U220/TM-U220II (Type A, B, and D)
Autocutting position to print start
position
27 mm 27 mm
Manual cut position to print start
position
20.2 mm Type D: 22.1 mm
Type A and B: 34.9 mm
Cutting method for partial cut One point on the left edge
uncut at center
(Type A and B only)
One point on the right edge uncut at right
position
(Type A and B only)
