3-14 Setup Rev. A
Use the memory switch (customize value) to specify settings such as buzzer enable/disable,
pattern, and amount of repetitions. See“Memory Switches” (page 3-20) for details about the
memory switches (customize value).
Note:
Be sure to always turn off the printer power when connecting or removing the optional external buzzer.
You cannot use an optional external buzzer at the same time as a cash drawer. Do not use a branch
connector or similar to connect both to a printer at the same time.
3.3.4.1 Installation location
We recommend installing the optional external buzzer at one of the locations shown below.
Note:
Do not install to a surface where roll paper is ejected.
Install so that the volume adjustment knob of the optional external buzzer is facing to the side or
downward in order to prevent liquid and similar from getting inside the buzzer.
