Epson TM-U220II Technical Reference Guide

Rev. A Setup 3-19
TM-U220II Technical Reference Guide
(*) Selection of dots between characters: On = 2 half dots, Off = 3 half dots
The number of characters per line in the Table indicates for the 76 mm-width paper.
Note:
May be 4K bytes depending on the model.
(*) Selection of dots between characters: On = 2 half dots, Off = 3 half dots
The number of characters per line in the Table indicates for the 76 mm-width paper.
DIP Switch 2
SW Function On Off
Default
ABD
1 Selects number of characters per line (cpl) (*) 42 cpl / 35 cpl 40 cpl / 33 cpl Off Off Off
2 Reserved (Autocutter) Enabled Disabled On On Off
3 Undefined - - Off Off Off
4 Serial communication set selection By memory switch By DIP switch Off Off Off
5 Undefined - - Off Off Off
6Reserved
(Flash memory rewriting)
Enabled Disabled Off Off Off
7 Pin 6 reset signal Used Not used Off Off Off
8 Pin 25 reset signal Used Not used Off Off Off
Parallel interface model
DIP Switch 1
SW Function On Off
Default
ABD
1 Auto line feed Enabled Disabled Off Off Off
2 Receive buffer 40 bytes 4KB/20KB* Off Off Off
3 Undefined - - Off Off Off
4 Undefined - - Off Off Off
5 Undefined - - Off Off Off
6 Undefined - - Off Off Off
7 Undefined - - Off Off Off
8 BUSY condition - Receive buffer-full - Offline
- Receive buffer-full
Off Off Off
DIP Switch 2
SW Function On Off
Default
ABD
1 Selects number of characters per line (cpl) (*) 42 cpl / 35 cpl 40 cpl / 33 cpl Off Off Off
2 Reserved (Autocutter) Enabled Disabled On On Off
3 Undefined - - Off Off Off
4 Undefined - - Off Off Off
5 Undefined - - Off Off Off
6Reserved
(Flash memory rewriting)
Enabled Disabled Off Off Off
7 Undefined - - Off Off Off
8 Pin 31 reset signal
(Parallel interface model)
Used Not used On On On
Undefined
(Other than Parallel interface model)
--OffOffOff
