Printing
Basic Operation from the Control Panel (XP-310 Series/
XP-410 Series only)
Printing photos from a memory card
Follow the steps below to print photos directly from a memory card.
Note for XP-410 Series:
You can print photos in various layouts. Select More Functions from the Home menu, and select Photo Layout Sheet, then
follow the on-screen instructions.
A
Load photo paper.
& “Loading Paper and Envelopes” on page 23
B
Insert a memory card.
& “Inserting a Memory Card” on page 26
C
Enter Print Photos mode from the Home menu.
D
Use l or r to select a photo and set the number of copies using the + or - button (use u or d for XP-310 Series).
Repeat this step for all the photos you want to print.
Note for XP-410 Series:
❏ If you have more than 999 images on your memory card, images are automatically divided into groups and the
group selection screen is displayed. Select the group that contains the image you want to print. Images are sorted
by the date they were taken.
❏ To select another group, select Print Photos on the Home menu. Then press d and select Select Group.
E
Display the print setting menus. For XP-410 Series, press d and select Print Settings. For XP-310 Series, press
OK and then press d.
Note for XP-410 Series:
You can crop and enlarge your photo. Select Crop/Zoom, and then make the settings.
F
Select the appropriate print settings such as paper size and paper type. Use u or d to select a setting item and use
l or r to change the setting. For XP-310 Series, press OK to save the changes.
G
Press x to start printing.
User’s Guide
Printing
31
