EDA 2530 Commissioning Procedure for Cable and Wireless Access

1/153 22-FGC 101 0239/2 Uen Rev J 2010-04-01

Commercial in confidence

197 (200)

Section 5.5; Added extra steps m, n, & o, to reboot the equipment in order

to update the change to the OBM IP address.

G 29-06-2009 Seventh Issue Changes:-

Additional configuration details added for Child#2 & Child#3 (EDA2530)

variants, which are subtended from CP SFP3 & SFP4 respectively.

Sec 7; Added Child#2/Child#3 CVID values range to the DLE Planning

table.

Sec 7.1; “Configure SFP Modules” – Defined the Parent CP port SFP3 to

subtend a Child#2. Defined the Parent CP port SFP4 to subtend Child#3.

Sec 7.2.3; Added new sub-section to configure CP port 3 for subtending

Child#2.

Sec 7.2.4; Added new sub-section to configure CP port 4 for subtending

Child#3.

Sec 7.5; Restructure existing section into sub-sections 7.5.1 to 7.5.3.

Sec 7.5.4; Added new sub-section detailing how to “Create S-VLANs on

the Parent to Subtend Child#2”.

Sec 7.5.5; Added new sub-section detailing how to “Create S-VLANs on

the Parent to Subtend Child#3”.

Sec 7.6; “Configure The IBM Sub-Interface” – Added C-VLAN id table to

include Parent, Child#2, & Child#3 values.

Sec 7.7; “Assign the IBM IP Address” – Redefine the L2 Interface Name

field to include the CVID value options for Parent, Child#2, & Child#3.

Sec 7.10; “Configure PVC Bridge Management” – Two new sets of PVC

config files available & organised into folders. Folder names are “PVC

Config Parent”, “PVC Config Child#2”, & “PVC Config Child#3”.

Sec 7.10.3 Two additional C-VLAN tables added for Child#2 & Child#3.

Showing C-VLAN value ranges of Child#2: 1201-1840 & Child#3: 2201-

2840.

H 24-02-2010 Eighth Issue Changes:-

Sections 1, 2, 3, and 5 amended to include 32 x SHDSL Units.

Section 3.3 Tools and Test Equipment lists revised to include SHDSL

modem, test telephone and HDF connectors.

Section 7 New table added with POTS site specific information required.

Various changes for Child#1 to be an EDA2510 or an EDA2530.
