TECHNICAL DATA
0740 801 028
- 12 -
© ESAB AB 2017
TECHNICAL DATA
PEK
Supply voltage 42 V, 50/60 Hz
Power requirement Max 900 VA
Engine connections adapted for ESAB's
motors
6 A 100%
Speed control Feedback from pulse encoder
Operating temperature -15°C to +45°C
Transportation temperature -20°C to +55°C
Relative air humidity Max 95%
Dimensions l×w×h 246 × 235 × 273 mm
Weight 6.6 kg
Enclosure class IP23
Travel speed 0–200 cm/min *)
See separate instruction manual for
automatic welding machines.
Max manual travel speed 2.0 m/min
Wire feed speed, filler wire 0–2500 cm/min *)
See separate instruction manual for wire feed
unit.
*) The setting range is dependent on the product used.
Enclosure class
The IP code indicates the enclosure class, i.e. the degree of protection against penetration
by solid objects or water.
Equipment marked IP23 is intended for indoor and outdoor use.
