INSTALLATION AND CONNECTIONS
0740 801 028
- 14 -
© ESAB AB 2017
USB connection (2)
An external USB memory can be used to transfer programs to and from the systems.
Certain USB memories may not work with this equipment. We recommend using USB
memories from a reputable supplier.
NOTE!
We recommend that the USB memory, that is used together with this equipment,
shall not be used for any other purpose.
NOTE!
ESAB assumes no responsibility for any damage caused as a consequence of
incorrect use of the USB memory.
CAN, connection for remote control unit or service tool (3)
Two CANbus connections (500 kbit/s) for external equipment, remote control or the ESAT
servicetool.
Termination of CANbus
Inside the unit there are CANbus terminations at two of the boards:
• 1AP1 MMC, switch SW1. Factory setting; NOT terminated.
• 26AP1 motor control board. jumper CN29. Factory setting; terminated to 120 Ohm.
LAN/Ethernet connector (10)
From serial no. 628-xxx-xxxx the PEK control unit is equipped with an Ethernet interface to
be able to connect the unit to an ESAB WeldCloud™ Mobile unit. For further information
about the WeldCloud™ system, see the WeldCloud™ instruction manual. For further
information about the WeldCloud™ Mobile unit, see the combined W8
2
and WeldCloud™
service manual.
