Checking the LED Indicators on board CB0
The indications are two coloured LED--indicators, red and green. One indicator can have
three indication states, off, red on, and green on. Three indicators are used which means
that 9 states can be indicated.
The following events will be indicated:
Event Indicator
1
Indicator
2
Indicator
3
Power on and boot program execution started red off off
Boot program has established contact, received red red red
Id--message *
Application start green green green
Application initiated (operationable)
(Flashing 0.25--4Hz)
green
(flashing)
off off
Watchdog timeout -- red --
Non recoverable communication error
(CAN bus off)
-- -- red
Program Loading started off green off
Program Loading in Progress
(Flashing every 20th CANmessage)
green
(flashing)
off off
Program Loading OK green green off
Program Loading Failure red green off
Default value set (Attribute memory reset) red green red
* In the boot master the program load timeout will produce this indication.
